Automotive



Its not just about you.

Security within the car shall effect all of you.

Automotive market is at the top-notch with all the radar sensors integrated together to understand the environment around the car.

Smart Radar System sees the future of automotive market that can innovate, ultimately taken up one level forward with radar sensors.





We protect you

by securely protecting your vehicle.

Protection and safety can never be held down for any reason when thinking about vehicles.

Seamless car protection made possible with Smart Radar System radar products will raise the bar of the automotive industry.

Enhancing the vehicle protection with sensors around the car will it serve as the perfect guardian to be protected.



If it was medieval times,

horses would have served

the trip better.

IRIS mounts on the corners, rear/front and side of a car to protect and alarm the driver. Medieval horses would have had much improvements in the service of each travel to enhance the road trip.

Even the time passes, Smart Radar System will enhance the efficiency to improve the human workflow, even whatever the device it serves for the past.





Automotive Applications for vehicles

Smart Radar System ADAS Solution

Smart Radar System is leading the development for many of the market segments where radar sensor can be adopted to fully utilize its values for better world. For the automotive solution, Smart Radar System currently develops and provides all-around detecting radar that can provide full 360° coverage for a single vehicle.



Automotive solution is where innovation can be adopted. Any sensor that can serve as innovative solution for the vehicle are competing in the automotive market. LiDAR, radar and optical camera sensors can provide its specific roles for automotive solution.



Products are specific to its coverage and usage as follows:

- IRISv: Corner Detecting MRR (Mid-Range Radar) to detect full 360°

- RETINA: Front/Rear Detecting LRR (Long-Range Radar) to detect longer range

     - RETINA 2L: 2-chip cascade radar, specifically targeting for the specifications to meet Long-Range detection capability.

     - RETINA 4W: 4-chip cascade radar, specifically targeting for the specifications to meet long-range detection capability.

IRISv, Corner Detecting Radar (Single-Chip Radar)



IRISv, the ultimate 360° detecting corner radar for its essential usage. Mounted all-around the corners of vehicle, IRISv system will provide the full mid-range coverage of radar sensor to understand mid-to-short range environment and serve as the most essential radar. IRISv has its unique advantages in that it will be adequate to perform fully inside the vehicle. Under the front/back bumpers of the car stationed on each side of the bumpers, will the IRISv system be fully monitoring the environment fully. IRISv, unlike the camera or Lidar will work fully under any unfriendly weather conditions (fog, rain, dust, snow, flare-proof). Even over walls in the corner environments will the radar solution acknowledge the object/human/environment in advance to provide alarms to the car.

RETINA, Multi-Chip Cascade Radar (RETINA2: 2-Chip Cascade Radar, RETINA4: 4-Chip Cascade Radar)



RETINA 2L & 4W will serve as LRR for the automotive vehicle. With the long-range detecting capability, the radar can oversee the longer range of the environment ahead from the vehicle to understand the characteristics in advance. RETINA 2L and 4W maybe both effective to understand the environment. With the radar chip cascade, RETINA inherently provide elevation information as well as the azimuth information to distinguish objects that are above the car-level. Distinguishing the elevation information is key to the ADAS solution as it will require elevation level of each objects detected to classify the danger levels. Smart Radar System is undergoing many of its products to testify for ADAS solution to understand the detection behavior and enhance the performance of each product ultimately.

RETINA 2L ADAS Driving Demo Test

(2-Chip Cascade Image Radar)

Vehicle: Ssangyong Tivoli

Mount Position: Front LRR (Long Range Radar)

Product Name: RETINA 2L (2-Chip Cascade Image Radar)

Azimuth FoV: ± 50°

Azimuth Angle Resolution: 8°

Elevation FoV: ± 15°

Elevation Angle Resolution: 13°

Summary:

ADAS Test result with RETINA2L (2-Chip Cascade Image Radar) The first reference radar to testify for the ADAS solution for LRR has been tested in Pangyo, South Korea. It brings up the bar for the radar's capability & competitiveness to be a solid solution for automotive sensor to undergo sensing for the surroundings. It can detect the height information and long range understandings to warn the car in advance to let real autonomous driving possible.

RETINA 4W ADAS Driving Demo Test

(4-Chip Cascade Image Radar)

Vehicle: Ssangyong

Tivoli Mount Position: Front LRR (Long Range Radar)

Product Name: RETINA 4W (4-Chip Cascade Image Radar)

Azimuth FoV: ± 30°

Azimuth Angle Resolution: 2°

Elevation FoV: ± 15°

Elevation Angle Resolution: 7°



Summary:

ADAS Test result with RETINA4W (4-Chip Cascade Image Radar) Second iteration radar to testify for the ADAS solution for LRR has been tested in Pangyo, South Korea. It brings up the bar for the radar's capability & competitiveness to be a solid solution for automotive sensor to undergo sensing for the surroundings. It can detect the height information and long range understandings to warn the car in advance to let real autonomous driving possible. The 4-Chip cascade solution provide much improved angular resolution for Azimuth and Elevation to differentiate close two objects. As the videos do suggest, the actual pointcloud itself are much smaller then the 2-chip cascade result. Smart Radar System, with the solution are trying to move up the bar even more to provide much resolute and accurate pointclouds to be more revolutionary.



Automotive Use Cases





Applications



Product: RETINA 4W

Application: Front / Back LRR









Product: IRISv

Application: 360 Detecting Corner MRR
